    Simon (PassMark)
    Administrator

  • Simon (PassMark)
    replied
    Originally posted by maddabbo View Post
    A few days ago I was benchmarking my new system and was getting 630 for 2D.

    Now I can only get about 450. I cant see what has changed on my system. All other scores are as good as before.
    Drivers haven't changed. No updates.
    It's a 3090 and is shown way below where it should be.
    Model average is 990? What could be set wrong that has lowered 2D so drastically?

    Thanks much
    It could be something running in the brackground that may have reduced the score.

    As for the overall low score, could be that your particular GPU driver version can result in lower scores. Or when used in combination with something else. (particular hardware, or overclocking settings, or some 3rd party software).

    Leave a comment:

  • maddabbo
    Newbie

  • maddabbo
    replied
    A few days ago I was benchmarking my new system and was getting 630 for 2D.

    Now I can only get about 450. I cant see what has changed on my system. All other scores are as good as before.
    Drivers haven't changed. No updates.
    It's a 3090 and is shown way below where it should be.
    Model average is 990? What could be set wrong that has lowered 2D so drastically?

    Thanks much

    Leave a comment:

  • David (PassMark)
    Administrator

  • David (PassMark)
    replied
    Aelfy,
    Thanks for follow up. Video card device drivers have been like this for decades, each release improves a few things, but breaks other things. I suspect the vendors are in such as rush to do each release (to line up with hardware releases) that they never do proper testing. Still it does seem to be a rare issue, so maybe it is only a problem when used in combination with something else (particular hardware, or overclocking settings, or some 3rd party software).

    Leave a comment:

  • Aelfy
    Junior Member

  • Aelfy
    replied
    Originally posted by David (PassMark) View Post
    There is no scrolling in the PDF test. It displays each page one after the other, but not with scrolling as you would see with the scroll bar. There should not be any pause. So if it was paused for 4 seconds of a 6 second test, that would explain the low result and also prove it isn't a calculation error (i.e. it seems to count the number of pages rendered correctly).

    Not sure why it is pausing. But from the 1000+ results we have for the 1660TI video card, no one else reported results under around 25 in the PDF render test. So it isn't a common issue.
    Okay I have some useful information after I downgraded the NVIDIA driver. I completely uninstalled all NVIDIA components of their most recent game ready driver 461.72. I then installed the oldest NVIDIA driver (driver only) I could find on their website for my 1660 ti - game ready version 457.30. All of the 2D graphics tests were higher and the PDF test was MUCH higher (54, 92nd percentile). The overall test result was much higher as well at 6593 (note this is with a +100 core overclock and +1000 memory overclock).

    So, to summarize, something is wonky with the latest NVIDIA driver 461.72 (game ready). Downgrading to 457.30 (game ready) worked better with Passmark Performance Test, yielding a reasonable score.

    Leave a comment:

  • David (PassMark)
    Administrator

  • David (PassMark)
    replied
    There is no scrolling in the PDF test. It displays each page one after the other, but not with scrolling as you would see with the scroll bar. There should not be any pause. So if it was paused for 4 seconds of a 6 second test, that would explain the low result and also prove it isn't a calculation error (i.e. it seems to count the number of pages rendered correctly).

    Not sure why it is pausing. But from the 1000+ results we have for the 1660TI video card, no one else reported results under around 25 in the PDF render test. So it isn't a common issue.

    Leave a comment:

  • Aelfy
    Junior Member

  • Aelfy
    replied
    I do see the 2d PDF render - It looks like 4 short bursts of scrolling, each followed by 1-2sec of pausing on a page, with the total of the time for the whole PDF test lasting maybe 6-7 seconds.

    Leave a comment:

  • David (PassMark)
    Administrator

  • David (PassMark)
    replied
    Aelfy, it is very unlikely it is a hardware problem. More likely it is a software / configuration issue.

    When you run the 2D PDF render test in PerformanceTest does it look slow? (i.e. does the benchmark score correspond to the visual experience).

    On a average machine the pages should flash past. At least 5 to 10 pages a second.


    Leave a comment:

  • Aelfy
    Junior Member

  • Aelfy
    replied
    I'm having the same problem of the incredibly low 2D score on the PDF test (in the 1st percentile). This is a with a brand new Dell G5 Gaming Desktop with i5-10400F, GTX 1660 Ti video card, 16GB ram, SSD. All the other scores are great. The PDF score can't be correct. I opened the TestPDF.pdf file and it scrolls through no problem using Acrobat. I tried disabling stuff with the inspectre tool mentioned above, but it didn't fix it. I tried installing the DX10 that someone suggested, but it didn't work. My windows 10 build is completely updated with Windows Update. I am using the most recent NVIDIA game ready driver ver 461.72. Now I'm worrying there could be something wrong with my computer - almost wish I didn't run the performance test. Any ideas?

    Leave a comment:

  • HHH03
    Junior Member

  • HHH03
    replied
    The 2D test has been poison for me ever since the Spectre/Meltdown patches came out. Unfortunately, these patches and AMD has made my rig very “outdated”. The 2D test can really reduce an awesome test score with a low 2D result... the only way I can achieve decent 2D scores is if I set Windows for “Adjust for best performance” and disable the Spectre patch. For some reason Meltdown patch doesn’t slow things up much if at all. The 3D performance is often better when Windows is set for “Adjust for best appearance” and Spectre/Meltdown patches are enabled.

    Leave a comment:

  • Radi_SVK
    Junior Member

  • Radi_SVK
    replied
    Originally posted by Richard (PassMark) View Post

    Within PerformanceTest's Manage Baseline feature, download and search for other submitted benchmarks with similar specs as yours and compare. The 2D Mark is computed from the individual tests, so see if your individual 2D scores are reasonable with others baselines.

    If you think it really is a problem, what are the individual scores for the 2D test.
    Hello Richard, thanks for that tip on filtering results. It was really helpful as I was able to filter results exactly for my CPU + GPU.. and while I did run just now extensive re-run of the 2D test will all kind of settings and everything is back to normal.. I was not able to determine the previous low score.. I am sure it was only momentary, perhaps something was running in the background that eats up resources.

    Leave a comment:

  • Richard (PassMark)
    Administrator

  • Richard (PassMark)
    replied
    Originally posted by Radi_SVK View Post
    Hello, I am in a same position as OP. Except I have a Top -end machine in tip top state from stability to maintenance.
    I have a 5800X machine running with 32GB of 3600MHz ram and as for the the point, or should I say on the issue.. I have an RTX 3080. Naturally, my system is way up there in the scores, but the 2D score is extremely low, 180 I think last time I checked.. Interested in the solution.
    Within PerformanceTest's Manage Baseline feature, download and search for other submitted benchmarks with similar specs as yours and compare. The 2D Mark is computed from the individual tests, so see if your individual 2D scores are reasonable with others baselines.

    If you think it really is a problem, what are the individual scores for the 2D test.

    Leave a comment:

  • Radi_SVK
    Junior Member

  • Radi_SVK
    replied
    Hello, I am in a same position as OP. Except I have a Top -end machine in tip top state from stability to maintenance.
    I have a 5800X machine running with 32GB of 3600MHz ram and as for the the point, or should I say on the issue.. I have an RTX 3080. Naturally, my system is way up there in the scores, but the 2D score is extremely low, 180 I think last time I checked.. Interested in the solution.

    Leave a comment:

  • RobertB
    Junior Member

  • RobertB
    replied
    Sorry for the late acknowledgement - I've been away for a few days.
    I am definitely on the trailing edge of technology - budget, and I like to fiddle about with the old stuff at a 90% discount. And solve mysteries if I can.

    Leave a comment:

  • David (PassMark)
    Administrator

  • David (PassMark)
    replied
    kapqa,

    Have a look at this post. It covers all the common performance issues
    Causes and Solutions for a slow PC

    Leave a comment:

  • kapqa
    Junior Member

  • kapqa
    replied
    Thank you for the explanation; i ran the test also on another computer with AMD APU A10-9700, and altough the difference is not so big between v9 and v10, it is still noticeable.
    So i am wondering now why the Graphics score is so much lower for the Nvidia Card, which in Theory should outperform the AMD APU Radeon R7 many times.
    Could it be that the card itself is somehow faulty or is it more related to the testing methodology/Nvidia - Windows 7 driver issues?

    Leave a comment:
